AGILAN A

Thermoplastic toe puff; single side adhesive; cotton support.

► AGILAN A 30    thickness - 0.80 ± 0.05 mm
► AGILAN A 32    thickness - 0.90 ± 0.05 mm
► AGILAN A 34    thickness - 1.00 ± 0.05 mm
► AGILAN A 36    thickness - 1.10 ± 0.05 mm
► AGILAN A 37    thickness - 1.30 ± 0.05 mm
► AGILAN A 38    thickness - 1.40 ± 0.05 mm

Sheet size:   100 cm. х 135 cm.
Way to cut:   diagonal
Skiving:          steel or rubber roll


Applications:
Toe has to be applied with the right pneumatic pressing machine equipped with heating plate, thermostat.

Temperature:   from 130 to 160°C
Activation:         from 5 to 12 sec., depending on thickness and temperature.
Pressure:           +/- 5 bar
